POLS 2580

Causal Inference in
Experimental Designs

Updated Dec 4, 2025

Overview

Estimands, Estimators and Estimates

Estimand the thing we want to know.
- Sometimes called a parameter ( $θ$ , “theta”) or quantity of interest
- The expected value of heights in POLS 2580 ( $θ = E [X]$ )
Estimator a rule or method for calculating an estimate of our estimand
- An average of a sample of 10 student’s heights in POLS 2580
- $\hat{θ} = \bar{x} = 1 / n * \sum_{1}^{n} x_{i}$
Estimate: a value produced by our estimator for some data
- The average of our 10 person sample is 5'10''

Potential outcomes notation

$Y_{i} (1)$ describes individual $i$ ’s outcome, $Y_{i}$ if they received the treatment $(D_{i} = 1)$
- Shorthand for $Y_{i} (D_{i} = 1)$
- Paul’s Covid-19 status ( $Y_{i}$ ) with the vaccine ( $D_{i} = 1$ )
$Y_{i} (0)$ describes individual $i$ ’s outcome, $Y_{i}$ if they did not receive the treatment $(D_{i} = 0)_{i}$
- Shorthand for $Y_{i} (D_{i} = 0)$
- Paul’s Covid-19 status ( $Y_{i}$ ) without the vaccine ( $D_{i} = 0$ )

The treatment received determines which potential outcome we actually observe:

$Y_{i} = (1 - D_{i}) * Y_{i} (0) + D_{i} * Y_{i} (1)$

Potential outcomes are fixed, but we only observe one (of many) potential outcomes $\to$ Fundamental Problem of Causal Inference

Potential Outcomes:

$Y_{i} (1)$	$Y_{i} (0)$	$τ_{i}$
7	3	4
8	6	2
5	4	1
4	3	1
6	10	-4
8	9	-1
5	4	1
7	8	-1
4	3	1
6	0	6

$E [Y_{i} (1)]$	$E [Y_{i} (0)]$	$E [τ_{i}]$
6	5	1

If we could observe everyone’s potential outcomes, we could calculate the ICE
On average eating chocolate increases happiness by 1 point on our 10-point scale (ATE = 1)
Suppose we conducted a study and let folks select what they wanted to eat.

Potential Outcomes:

$Y_{i} (1)$	$Y_{i} (0)$	$τ_{i}$
7	3	4
8	6	2
5	4	1
4	3	1
6	10	-4
8	9	-1
5	4	1
7	8	-1
4	3	1
6	0	6

$E [Y_{i} (1)]$	$E [Y_{i} (0)]$	$A T E$
6	5	1

Observed Treatment:

$x_{i}$	$d_{i}$	$y_{i}$
chocolate	1	7
chocolate	1	8
chocolate	1	5
chocolate	1	4
fruit	0	10
fruit	0	9
chocolate	1	5
fruit	0	8
chocolate	1	4
chocolate	1	6

${\bar{y}}_{d = 1}$	${\bar{y}}_{d = 0}$	$\hat{A T E}$
5.57	9	-3.43

Observed Treatment:

$x_{i}$	$d_{i}$	$y_{i}$
chocolate	1	7
chocolate	1	8
chocolate	1	5
chocolate	1	4
fruit	0	10
fruit	0	9
chocolate	1	5
fruit	0	8
chocolate	1	4
chocolate	1	6

${\bar{y}}_{d = 1}$	${\bar{y}}_{d = 0}$	$\hat{A T E}$
5.57	9	-3.43

Selection Bias

Our estimate of the ATE is biased by the fact that folks who prefer fruit seem to be happier than folks who prefer chocolate in this example
In general, selection bias occurs when folks who receive the treatment differ systematically from folks who don’t
What if instead of letting people pick and choose, we randomly assigned half our respondents to chocolate and half to receive fruit

Potential Outcomes:

$Y_{i} (1)$	$Y_{i} (0)$	$τ_{i}$
7	3	4
8	6	2
5	4	1
4	3	1
6	10	-4
8	9	-1
5	4	1
7	8	-1
4	3	1
6	0	6

$E [Y_{i} (1)]$	$E [Y_{i} (0)]$	$A T E$
6	5	1

Randomly Assigned Treatment:

$x_{i}$	$d_{i}$	$y_{i}$
chocolate	1	7
chocolate	1	8
chocolate	0	4
chocolate	1	4
fruit	0	10
fruit	1	8
chocolate	0	4
fruit	0	8
chocolate	1	4
chocolate	0	0

${\bar{y}}_{d = 1}$	${\bar{y}}_{d = 0}$	$\hat{A T E}$
6.2	5.2	1

Randomly Assigned Treatment:

$x_{i}$	$d_{i}$	$y_{i}$
chocolate	1	7
chocolate	1	8
chocolate	0	4
chocolate	1	4
fruit	0	10
fruit	1	8
chocolate	0	4
fruit	0	8
chocolate	1	4
chocolate	0	0

${\bar{y}}_{d = 1}$	${\bar{y}}_{d = 0}$	$\hat{A T E}$
6.2	5.2	1

Random Assignment

When treatment has been randomly assigned, a difference in sample means provides an unbiased estimate of the ATE
The fact that our $\hat{A T E} = A T E$ in this example is pure coincidence.
If we randomly assigned treatment a different way, we’d get a different estimate.
In general unbiased estimators will tend to be neither too high nor too low (e.g. $E [\hat{θ} - θ] = 0$ ])

Estimating an Average Treatment Effect

If we treatment has been randomly assigned, we can estimate the ATE by taking the difference of means between treatment and control:

$\begin{aligned} E [\frac{\sum_{1}^{m} Y_{i}}{m} - \frac{\sum_{m + 1}^{N} Y_{i}}{N - m}] & = \overset{\begin{array}{c} Average outcome \\ among treated \\ units \end{array}}{\overset{⏞}{E [\frac{\sum_{1}^{m} Y_{i}}{m}]}} - \overset{\begin{array}{c} Average outcome \\ among control \\ units \end{array}}{\overset{⏞}{E [\frac{\sum_{m + 1}^{N} Y_{i}}{N - m}]}} \\ = E [Y_{i} (1) | D_{i} = 1] - E [Y_{i} (0) | D_{i} = 0] \end{aligned}$

That is, the ATE is causally identified by the difference of means estimator in an experimental design

Random Assignment 1

$x_{i}$	$d_{i}$	$y_{i}$
chocolate	1	7
chocolate	1	8
chocolate	0	4
chocolate	1	4
fruit	0	10
fruit	1	8
chocolate	0	4
fruit	0	8
chocolate	1	4
chocolate	0	0

${\bar{y}}_{d = 1}$	${\bar{y}}_{d = 0}$	$\hat{A T E}$
6.2	5.2	1

Random Assignment 2

$x_{i}$	$d_{i}$	$y_{i}$
chocolate	0	3
chocolate	1	8
chocolate	0	4
chocolate	1	4
fruit	1	6
fruit	1	8
chocolate	0	4
fruit	1	7
chocolate	0	3
chocolate	0	0

${\bar{y}}_{d = 1}$	${\bar{y}}_{d = 0}$	$\hat{A T E}$
6.6	2.8	3.8

Random Assignment 3

$x_{i}$	$d_{i}$	$y_{i}$
chocolate	1	7
chocolate	0	6
chocolate	1	5
chocolate	1	4
fruit	0	10
fruit	0	9
chocolate	0	4
fruit	1	7
chocolate	1	4
chocolate	0	0

${\bar{y}}_{d = 1}$	${\bar{y}}_{d = 0}$	$\hat{A T E}$
5.4	5.8	-0.4

Why Random Assignment Matters?

Formally, randomly assigning treatments creates statistical independence $(⫫)$ between treatment ( $D$ ) and potential outcomes ( $Y (1), Y (0)$ ) as well as any observed ( $X$ ) or unobserved confounders ( $U$ ):

$Y_{i} (1), Y_{i} (0), X_{i}, U_{i} ⫫ D_{i}$

Practically, what this means is that what we can observe ( differences in conditional means for treated and control ), provide good (unbiased) estimates of what we’re trying to learn about (Average Treatment Effects)
